Baosiwei 2513 UV Flatbed Printer | Large Format Industrial Digital Printing Machine 2.5m x 1.3m
- Category: UV Flatbed Printer
- SKU: JW-2513M
- Printing Size: 2500× 1250 mm ± 2 mm
- Application Materials: Glass, acrylic, metal panels, wood panels, tiles, PVC panels, corrugated panels, plastics, etc.
- Stable and excellent performance, low-cost flatbed printer.
- Standard LED water-cooled UV lamp, good curing effect.
- Independent control suction system, and uniform adsorption force to ensure the smooth printing of materials.
- Imported linear mute guide, low noise, high precision, and smooth operation.
- White, color, and varnish printing out three layers of ink in one go.
Product Details
Payment & Shipping Terms
Multi-Panel Ink Wash Embossed Painting - High Precision UV Printing
Gold Foil Embossed Abstract Wall Art - UV Printer Gold Stamping Effect
3D Embossed Textured Art Painting - UV Flatbed Printer Relief Effect Welcome to the wonderful world of UV flatbed printers, where the boundary between technology and art is redefined. With their superior print quality and unrivaled efficiency, our UV flatbed printers are the right-hand men for the modern creative industries.
UV flat panel printing technology with its unique advantages, so that your creativity can be perfectly presented. Whether it is high-definition and delicate images or a rich variety of colors, you can be perfectly displayed on our UV flatbed printers. At the same time, the efficient printing speed makes your production process smoother and easily cope with various large-scale printing needs.
Related Products
Baosiwei New Generation Visual Positioning UV Flatbed Printer
Baosiwei A3 Multifunctional UV Flatbed Printer Small
Baosiwei New Generation Visual Positioning UV Flatbed-Printer 1.6mx1.2m
Baosiwei 6090 UV Flatbed Printer – High-Precision & Industrial-Grade Printing for Small Items & Signage Specifications
| Model | JW-2513M / JW-2513G6 |
| Print head | Ricoh G5 / G6 |
| Numbers of print heads | 2-8 |
| Printing speed | Standard mode (Single row of printheads): 30 ㎡/h |
| Production mode (Single row of printheads): 22 ㎡/h | |
| High-resolution mode (Single row of printheads): 18 ㎡/h | |
| Printing size (W x D) | 2500× 1250 mm ± 2 mm |
| Media weight | 300KG |
| Media type | Glass, ceramic tiles, metal plates, acrylic, wooden boards, PVC boards, coated paper, etc. |
| Media thickness | 0.1-90mm |
| Ink type | Special UV ink for Ricoh printheads |
| lnk configuration | Choices of CMYK+Lc+Lm+W, CMYK+W, CMYK+Lc+Lm+W+V, and CMYK+W+V |
| Ink capacity | 1Kg / bottle |
| Connectivity | Gigabit |
| Environment | Self-contained, clean, low-dust, well-ventilated |
| Temperature : 18-30°C;Humidity: 30-70%RH | |
| Power requirements | AC220V (±5%),50HZ/60HZ |
| Power consumption | 6,800W |
| Machine dimensions (W x D x H) | 4,640 ×2,125 × 1,460 mm (±10 mm) |
| Machine weight | 1,300 Kg |
| Shipping dimensions (W x D x H) | 4,880× 2,360× 1,850 mm |
| Shipping weight | 1,700kg |
| Optional Visual Positioning System available | Cannon-style Visual Position System |
| RIP software | Standard: RIIN ; Optional: PrintFactory / |
| Uitraprint /Onyx / PhotoPrint | |
| Print resolution | 960 x 900 dpi; 960 × 1200 dpi; 720 × 2400 dpi |
| Computer requirements | Operating system: Windows 7/10(64-bit);Procssor: Intel Core i7;Memory: 16 GB; Hard-disk: 1TB or above SSD drive; USB3.0port. |
Company Profile
Marketed under our own brand Baosiwei, Pros-View is a leading manufacturer specializing in manufacturing, research and development, production, sales, and services. The company was established in 1996 with headquarters in Guangzhou, China. Since then, we have successfully expanded our reach, covering 18 cities nationwide, and established 2 subsidiary companies overseas. We are also an authorized dealer for the international brands such as ROLAND, RICOH Latex, and others.
Our continuous success stems from our unwavering commitment to solution development. Collaborating closely with various industries, we tailor digital printing solutions to meet their specific needs. At the heart of our development lies our Solution Development Center, spanning 500 sq meter and staffed by a dedicated team of over 10 specialists. Over the years, we have successfully developed and implemented more than 1800 innovative solutions.
In addition, Baosiwei partnered with X-Rite to establish the X-Rite Certified Color Lab within our Solution Development Center. This collaborative effort means that our lab meets the rigorous standards and requirements set by X-Rite. Furthermore, our specialists have undergone X-Rite's comprehensive color management training, further enhancing our expertise and capabilities in color science.
We are committed to delivering exceptional after-sales service and support, aiming to minimize machine downtime for our customers. Through our exclusive Pros-View Service app, customers can easily initiate video calls with our support team at the press of a button on their mobile devices. At the same time, our state-of-the-art back-end system enables seamless tracking and resource allocation for efficient resolution of service calls.
Baosiwei remains steadfast in our dedication to providing unparalleled services and technical support to our valued customers. We focus on offering environmentally friendly and high-quality digital printing equipment, as well as comprehensive one-stop digital printing solutions. Our very existence is to bring value to customers.
