Baosiwei 1.8m Eco-Solvent Roll-to-Roll Printer 4 color
- Category: Eco Solvent Printer
- SKU: JW-1804
- Print Width: 1800mm
- Application Materials: Leather, canvas, backlit film, car sticker, photographic paper, outdoor PP, silk cloth, etc.
- 4 i3200-E1 or A1 printheads for stable and high-speed production.
- Equipped with 3-stage (pre, platen, post) media heating system and super long front dryer for best
printing efficiency. - Multiple ink configurations available: 1) CMYKLcLmLkLlk, 2) CMYKLcLmLkRed, 3) CMYKGrOrBlueRed.
- Dual power feeding and take-up system to ensure accurate media advancing.
- Extended drying distance (8-color configuration only) to reduce drying energy and ensure printing at
full speed. - The front dryer is equipped with a back plate to optimize drying efficiency at reduced energy.
Product Details
Payment & Shipping Terms



Large Format Eco Solvent Printer 1.8m 4pc i3200 4-Color
Choices of 4 / 8 color ink configurations with smoother color transitions.
- 4 i3200-E1 or A1 printheads for stable and high-speed production.
- Equipped with a 3-stage (pre, platen, post) media heating system and super long front dryer for best printing efficiency.
- Multiple ink configurations available: 1) CMYKLcLmLkLlk, 2) CMYKLcLmLkRed, 3) CMYKGrOrBlueRed.
- Dual power feeding and take-up system to ensure accurate media advancing.
- Extended drying distance (8-color configuration only) to reduce drying energy and ensure printing at full speed.
- The front dryer is equipped with a back plate to optimize drying efficiency at reduced energy.
Applications
Introducing our cutting-edge large-format Eco Solvent Printer equipped with 8 colors, we bring forth a world of limitless possibilities for your printing needs. With an expanded color gamut and enhanced precision, this printer opens new horizons in design and production. Its versatility extends to various applications, including indoor and outdoor signage, banners, posters, and backlit displays. The addition of additional colors allows for enhanced color depth, smooth gradients, and precise color matching, ensuring your prints are vivid, lifelike, and true to your original vision.
Related Products
Specifications
Model | JW-1804 | |
Print head | Licensed Epson i3200-E1 / i3200-A1 | |
Number of printheads | 4 | |
Printing speed | 4-color 4 pass: 70 sqm/h 6 pass: 35 sqm/h | 8-color 4 pass: 35 sqm/h 6 pass: 25 sqm/h |
Printing width | Maximum 1.8 m | |
Media type | Various types of indoor/outdoor roll-to-roll signage media and decorative material. | |
Media advancing | Dual powered take-up and feeding system. | |
Ink type | Eco-solvent / Aqueous | |
Ink configuration | 4-color CMYK | Optional 8-color CMYKLcLmLkLIk CMYKLcLmLkRed CMYKGrOrBlueRed |
Ink capacity | 1 kg/bottle | |
Ink supply | Bulk ink system | |
Connectivity | Gigabit | |
Environment | Temperature: 20 - 30°C; Humidity: 45% - 65% RH | |
Media heating system | 3-stage heating: Pre, Platen, Post | |
Media dryer | Front media dryer (Dryer power: 5400 W) | |
Power requirements | AC 220V / 110V (±5%), 50/60 Hz | |
Power consumption | 1200 W | |
Machine dimensions (W×D×H) | 3040 × 950 × 1770 mm | |
Machine weight | 287 kg | |
Shipping dimensions (W×D×H) | 3180 x 840 x 750 mm | |
Shipping weight | 365 kg | |
RIP software | PhotoPRINT / MainTOP/ RIIN (optional) | |
Computer requirements | Operating system: Windows 7/10 (64-bit); Processor: Intel Core i7; Memory: 16 GB; Hard-disk: 1TB or above SSD drive; USB 3.0 port |
