产品
宝斯威60cm 4个i3200-A1喷头DTF打印机
服装烫金DTF印花机
荧光墨DTF打印机
4头DTF打印设备
- 类别: DTG & DTF 印花机
- SKU: BSW-T604
- 打印宽幅: 60cm
- 应用材料: T 恤、牛仔夹克、运动服、帽子、鞋、牛仔裤、等。
产品属性
喷头类型
4 个官方授权的Epson i3200-A1
打印宽幅
60cm
打印速度
4 pass 22㎡/h 6 pass 17㎡/h
墨水类型
水性颜料墨水
墨水配置
8色 白墨
付款和运输条款
最小订购量
1 套



宝斯威 60cm DTF 热转印打印机
专为服装个性定制打造的环保型打印解决方案
满足多样化个性定制需求
本机型采用热转印直喷工艺,输出图案边缘整洁,颜色鲜亮,兼容多种面料,是服装定制行业的理想选择。
核心优势
• 无白边残留,切割贴膜干净利落
• 在深色面料上不透底,遮盖力强
• 耐刮耐洗,墨水不返潮,持久稳定
• 支持荧光墨水与烫金解决方案,提升产品附加值
高速与高精度兼备
• 搭载爱普生 i3200-A1 工业喷头,实现高速高精图像输出
• 采用 汉森 控制系统,运行稳定,兼容性强,易操作
图像清晰,表现力丰富
• 渐变自然、线条清晰、细文字也能精准呈现
• 荧光与烫金方案可灵活组合,打造差异化产品视觉效果
广泛适配多种服装面料
本款 DTF 打印方案适用于棉布、涤纶、牛仔、氨纶、帆布等多种服饰材料,适合以下场景:
• T恤、卫衣定制
• 运动服、潮流服饰
• 牛仔类服装与时尚配饰
• 帽子、包袋、活动周边类产品
助力服装定制差异化发展
四喷配置支持大批量快速输出,满足定制化市场需求。配合荧光、烫金等特效方案,帮助企业打造更具辨识度的产品,提升品牌竞争力。
欢迎通过 [email protected] 联系我们,申请免费样品或了解更多解决方案。
相关产品
规格参数
DTF Printer | ||
Model | T602 | T604 |
Print head | Licensed Epson i3200-A1 | |
Number of printheads | 2 | 4 |
Printing speed | 4 pass: 12 sqm/h 6 pass: 10 sqm/h | 4 pass: 22 sqm/h 6 pass: 17 sqm/h |
Printing width | Max.60 cm | |
Media type | DTF transfer film | |
Ink type | Water based DTF pigment ink | |
Ink configuration | 4 Color + White | 8 Color + White |
Ink capacity | 1 kg/bottle | |
Connectivity | Gigabit | |
Environment | Temperature 20 - 30 °C; Humidity 45% - 65% | |
Power requirements | AC 220V ±10%, 50 - 60 Hz | |
Power consumption | 350 W | |
Machine dimensions(W x D x H) | 1755 x 770 x 1600 mm | 1755 x 770 x 1600 mm |
Machine weight | 150 kg | 152 kg |
Shipping dimensions (W x D x H) | 2135 x 875 x 780 mm | 2135 x 875 x 780 mm |
Shipping weight | 210 kg | 220 kg |
RIP software | Standard: MainTop; Optional: PhotoPRINT | |
Computer requirements | Operating system: Windows 7/10 (64-bit); Processor: Intel Core i7; Memory: 16 GB; Hard disk: 1TB or above SSD drive; USB 3.0 port |
DTF Shaker/Dryer | ||
Model | H650 | H6501 |
Power requirements | AC 220V ±10%, 50/60 Hz | AC 220V ±10%, 50/60 Hz |
Power consumption | 3500 - 5000 W | 5500 - 7900 W |
Machine dimensions (W x D x H) | 1953 x 1002 x 1081 mm | 2589 x 1002 x 1081 mm |
Machine weight | 240 kg | 270 kg |
Shipping dimensions (W x D x H) | 1930 x 1120 x 1140 mm | 2190 x 1120 x 1140 mm |
Shipping weight | 290 kg | 360 kg |
Fume Extractor | ||
Model | JS100 | |
Power requirements | AC 220V ±10%, 50/60 Hz | |
Power consumption | 440 W | |
Machine dimensions (W x D x H) | 530 x 571 x 1366 mm | |
Machine weight | 95 kg | |
Shipping dimensions (W x D x H) | 690 x 630 x 1540 mm | |
Shipping weight | 122 kg |
