Products
Baosiwei Eco Solvent Hybrid Printer high speed leather production
High Speed Eco Solvent Hybrid Printer
Leather Printing Solution
Wide Format Eco Solvent Printer
- Category: Hybrid Printer
- SKU: JW-1908 ECO
- Print Width: 1800mm
- Application Materials: Leather goods manufacturing, Interior decoration, Home furnishing, Advertising and signage, Commercial display
- Accuracy of low-speed machines with minimal feathering path and banding effects.
- Equipped with 8 i3200-E1 printheads for high-speed and stable production.
- Upgraded servo motors and control system for increased stability.
- The vacuum platform is expanded to 80 cm in length to ensure that the media are placed more evenly.
- High-speed production of 100 - 140 sqm/h, comparable to imported machines.
Product Details
Print Head
8 Licensed Epson i3200-E1
Print Width
1.8m
Printing speed
4 pass: 100-140㎡/h
Ink Type
i3200 Eco-solvent special ink
Ink Configuration
4 Color / 8 Color (CMYK, LC, LM, LK, LLK)
Payment & Shipping Terms
Minimum Order Quantity
1 set
Baosiwei Eco-Solvent Printer – High-Resolution Custom Leather Bag Printing for Fashion & Accessories
Baosiwei Eco-Solvent Printer – Artistic Wall Decor and Framed Posters Printing for Interior Design
Baosiwei Eco-Solvent Printer – Durable and Stylish Custom Carpet & Mat Printing for Home & Commercial Use 8-Head High-Speed Eco-Solvent Hybrid Printer
Advancing Performance Through Enhanced Stability and Quality
Superior lmage Resolution
Consistent output in printing quality, with no color banding and feathering defects. Equipped with 8 Epson i3200-E1 printheads delivering superior print resolution and rich detail reproduction.
High-Volume Production Capacity
- Production speeds of 100-140m²/h.
- Optional large-roll media handling system.
- Optimized for high-volume orders with reduced material handling time
Advanced Media Transport System
Heavy-duty conveyor belt mechanism ensuring：
- Precise step accuracy
- Stable media feeding
- Minimal media skewing
- Reduced material wrinkling
- Continuous printing operation
Premium Engineering Features
- AC servo motor system
- lmported linear silent guide rails
- Precision printhead motion control
- Extended 80cm vacuum platform
- Enhanced flatbed and roll-to-roll printing capabilities
Flexible Configuration Options
Available in two printing widths: 1.8-meter model or 2.1-meter model. Providing versatile solutions for diverse production requirements and specific industry applications.
FREE Printed Sample
We cordially invite you to request complimentary print samples utilizing your preferred media, please do not hesitate to contact us [email protected].
Related Products
Baosiwei UV Hybrid Leather Printing Printer 1.9m
Baosiwei 3D Embossed oil painting UV Hybrid Printer 1.9m
Baosiwei High Speed Processed UV Hybrid Printer
Baosiwei Eco Solvent Hybrid Printer 1.9m Large Format 4pcs i3200
Baosiwei water-based Latex Digital Printer 1.9m Specifications
| Model | JW-1908 |
| Print head | Licensed Epson i3200-E1 |
| Numbers of print heads | 8 |
| Head height | 2-30 mm (adjustable) |
| Printing speed | 4 pass: 100-140㎡/h |
| Printing width | Maximum 1800 mm |
| Media type | Plates and rolls media. Suitable for leather, home decoration, signage, etc. applications |
| Media width | Maximum 1900 mm |
| Media advancing | Industrial mesh belt |
| Ink type | i3200 eco-solvent special ink |
| lnk configuration | 4 Color / 8 Color (CMYK, LC, LM, LK, LLK) |
| Ink capacity | 1Kg / bottle |
| Connectivity | Gigabit |
| Environment | Temperature: 15-28℃; Humidity: 35-80% RH |
| Heating/drying | Infrared + Fan; Power consumption: 3,600 W |
| Power requirements | AC220V / 110V(±5%),50HZ / 60HZ |
| Power consumption | >20A; 3,500 W |
| Machine dimensions (W x D x H) | 3,700× 1,785 × 1,640 mm |
| Machine weight | 1,175kg(Pneumatic shaft) |
| Shipping dimensions (W x D x H) | 3,845× 1,810 × 1,610 mm |
| Shipping weight | 1,235kg |
| RIP software | PhotoPRINT /MainTop / PrintFactory (Optional) |
| Computer requirements | Operating system: Windows 7/10(64-bit);Procssor: Intel Core i7;Memory: 16 GB; Hard-disk: 1TB or above SSD drive; USB3.0port. |
